SX460 AVR diesel generator automatic voltage regulator engine control voltage board brushless AC generator compatible
technical specifications
Steady state voltage adjustment rate: ≤ ± 1%
Voltage regulation range: ≥ 15%
Resistance: ≥ 5 ohms
Frequency: 50-60Hz
Input power supply: 7.8=100V~265V AC 50/60Hz
Maximum voltage: 90 V DC, 207 V AC Input DC: 4A DC
Maximum current: 6A for 10 seconds
Temperature range for use: -40 º C~60 º C
Packaging size: 175 * 150 * 65mm
Packaging weight: 360g
Material: ABS PCB
Color: Black
Packaging content: One SX460 AVR and one user manual
